Sports Box: A TV Wall in One Browser Window

A sports bar puts eight games on the wall and one announcer in the room. At home I had the opposite: a pile of tabs, every one of them trying to talk, and the score living in a tab I had already left.

So I built Sports Box — a multiview dashboard that ships inside a Chrome extension. Up to 16 streams in one window, one channel audible, a scorebug on the panel you linked to that game. Source: github.com/mitchelldawkinsjr/sports-box. Architecture notes: Sports Box project page.

The product in one sentence

Paste the games. Pick which one you can hear. Glance the slate without leaving the picture.

A webpage cannot do this job alone

Iframes are how you put two pages in one window. They are also how sites refuse to be put in a window. X-Frame-Options and a CSP frame-ancestors rule blank the panel before the stream starts. Login cookies for ESPN, the league sites, and the subscription apps are not sent into a frame, so that panel spins on a login wall.

The dashboard is a React app. The part that makes the wall work is a Manifest V3 extension:

• declarativeNetRequest strips X-Frame-Options and CSP on http and https responses, main frame and subframe
• a page-world script owns mute, because the player's own JavaScript ignores an isolated content script
• login-gated sites open as their own Chrome window, snapped to the panel, and the picture is mirrored back

npm run build:ext writes the dashboard into extension/app. The toolbar icon opens that page. No Vite server on game day.

What each URL becomes

resolveEmbed sorts a paste into a player before the panel mounts anything.

URL	What the panel does
YouTube, Twitch, Vimeo	Official embed. Mute goes through the player API, so the iframe does not reload
.m3u8	hls.js inside the panel
Spectrum	Iframe, after the extension removes the frame headers. sportsbox=1 marks it for Fill video
ESPN, league sites, subscription apps	A docked Chrome window. The session stays on a real tab

Anything else is an iframe and gets the same frame-header treatment.

One announcer

Solo is the move that matters. That panel comes up. Every other panel is muted. The button does it, so does ⌘/Ctrl+1 through 9, and so does clicking a ticker game that is already linked to a panel. A plain unmute still exists when you want two feeds, but the wall is built around one voice. Watch mode prints AUDIO ON-AIR with the channel number on every panel that is actually audible.

Embed pages set video.muted back on their own. An isolated content script can write the property and lose the next play(). mute-main.js runs in the page world (world: "MAIN"), patches HTMLMediaElement.prototype.play, and walks open shadow roots. The service worker applies that state per panel. One unmute must not wake the other fifteen.

Docked windows stay separate. Sound stays on the source tab. The mirror <video> in the panel is picture only, so the game is not doubled.

Fill video, one panel at a time

A lot of these pages are a player under a header, a chat column, and ads. Fill video hides that chrome and pins the player to the frame.

The dangerous version fills every iframe in the tab. Sports Box names each panel iframe sb-${panelId}. webNavigation.getAllFrames walks the parent chain from that frame, and chrome.scripting runs only on that tree. Nested players are included. The panel next door is not.

Inside the frame, the content script scores <video> nodes by whether they are playing, ready, and how much area they cover. Player iframes get a bonus. Ad frames get dropped. The winner is marked sports-box-target. focus.css hides everything else and fixes that node to the viewport.

Scores on the game you are watching

The ticker reads ESPN's public scoreboard for the NFL, college football, the NBA, and the WNBA. Link a panel to a game and the scorebug sits on that picture. Hover a ticker row for the network. Click it to focus the panel already linked to that game.

College football TV data is optional. A CollegeFootballData key can fill the network. The result is cached in localStorage, and Sports Box will not ask again for three hours. A soft cap at 800 calls leaves headroom under the free 1,000 a month. Live scores stay on ESPN either way. The paid CFBD scoreboard route is opt-in. A free key never polls it.

Close games raise a banner. Football qualifies within one score in the fourth or overtime, and within a possession late in the third. Basketball qualifies within eight in the fourth or overtime, and within five late in the third. If that game is linked to a panel, the banner names the channel.

The phone is the remote

The wall is full screen. I did not want to get up to swap audio.

npm run remote starts a Node HTTP server on port 8787, bound to the LAN, with a four-digit PIN minted for that process. The desktop opens a Server-Sent Events stream as the host and pushes board state. The phone opens the keypad on the same Wi-Fi — QR code or the printed URL — and posts commands with that PIN. Solo, volume, mute, swap, box count, matrix preset, Watch or Edit.

The hub is a few hundred lines of node:http. It dies when the terminal does. There is no account on the other side of it.

Layouts that survive a refresh

Four matrix presets: an equal grid, a 1+N hero, a forced 3-column board, and a wide strip. One to sixteen panels. Named layouts and the live board live in localStorage. Watch hides the URL bars. Control opacity and scorebug opacity fade on their own. Escape leaves showtime.

Stack

Piece	Choice
UI	React 19, TypeScript, Vite
Ship	Vite build written into the extension package
Extension	Manifest V3 — declarativeNetRequest, scripting, webNavigation, tabs, windows
HLS	hls.js
Scores	ESPN scoreboard JSON, optional CFBD media
Remote	Node http, Server-Sent Events, a PIN, same Wi-Fi

No database. Layouts stay in the browser. The only process you leave running is the remote hub, and only while the phone is in your hand.

Source: github.com/mitchelldawkinsjr/sports-box · Build notes: /projects/sports-box.
